| The following products have been discontinued. The
column on the right of the table lists a link to the last driver available for each particular product. For further
information on products/operating systems/driver support, see here.
|
Model |
Sample Rate |
Formats |
Analog
Inputs* |
Analog
Outputs* |
AES3
Inputs |
AES3
Outputs |
Play
Streams |
Record
Streams |
Other |
Last Driver
Available for Product
|
|
ASI2118 |
- |
NTSC Video |
8 tuners |
8 CVBS and unbalanced audio |
0 |
0 |
0 |
0 |
1RU Rackmount
8 NTSC video/audio tuners |
- |
|
ASI2214 |
Multi (MRX)
8-96kHz |
PCM 8,16,32
MPEG Layer 2
MP3 |
1 |
4 |
1 |
1 |
4 |
2 |
TSX time scaling
|
N/A |
|
ASI4111 |
Multi
8-50kHz |
PCM
MPEG Layer 2 |
1 |
1 |
1 |
1 |
2 |
1 |
|
2.97 |
|
ASI4113 |
Multi
8-50kHz |
PCM
MPEG Layer 2 |
1 |
3 |
1 |
1 |
4 |
1 |
|
2.97 |
|
ASI4215 |
Multi
8-50kHz |
PCM 8,16
MPEG Layer 2
DolbyAC2 (play) |
1 |
5 |
1 |
4 |
4 |
1 |
|
3.08.06 |
|
ASI4312 |
Single
8-50kHz |
PCM
MPEG Layer 2 |
1 |
2 |
0 |
0 |
4 |
1 |
|
3.08.06 |
ASI4332
and
ASI4334 |
Single
8-50kHz |
PCM
MPEG Layer 2 |
3 |
4 |
0 |
0 |
4 |
1 |
|
3.08.06 |
|
ASI4336 |
Single
8-50kHz |
PCM
MPEG Layer 2 |
3 |
4 |
0 |
0 |
4 |
2 |
8 Relay Outputs
16 Optoisolated inputs
RS422 MPEG bitstream input |
3.08.06 |
|
ASI4342 |
Single
8-50kHz |
PCM 8,16
MPEG Layer 2
MP3 (play only) |
1 |
2 |
0 |
0 |
4 |
1 |
|
3.08.06 |
|
ASI4344 |
Single
8-50kHz |
PCM 8,16
MPEG Layer 2
MP3 (play only) |
3 |
4 |
0 |
0 |
4 |
1 |
|
3.08.06 |
|
ASI4346 |
Single
8-50kHz |
PCM 8,16
MPEG Layer 2
MP3 (play only) |
3 |
4 |
0 |
0 |
4 |
1 |
8 Relay Outputs
16 Optoisolated inputs
RS422 MPEG bitstream input |
3.08.06 |
|
ASI4501 |
Multi
8-50kHz |
PCM
MPEG Layer 2 |
1 |
5 |
1 |
1 |
4 |
1 |
|
2.97 |
|
ASI4502 |
Multi
8-50kHz |
PCM
MPEG Layer 2 |
1 |
1 |
1 |
1 |
1 |
1 |
|
2.97 |
|
ASI4503 |
Multi
8-50kHz |
PCM
MPEG Layer 2 |
0 |
5 |
0 |
1 |
4 |
0 |
|
2.97 |
|
ASI5041 |
32-192kHz |
PCM
8,16,24,32 |
0 |
0 |
4 |
4 |
12
(2 SSX) |
8
(1 SSX) |
|
current |
|
ASI5042 |
32-192kHz |
PCM
8,16,24,32 |
4 |
4 |
0 |
0 |
12
(2 SSX) |
8
(1 SSX) |
|
current |
|
ASI5044 |
32-192kHz |
PCM
8,16,24,32 |
4 |
4 |
4 |
4 |
12
(2 SSX) |
8
(1 SSX) |
|
current |
|
ASI5402 |
Multi
8-96kHz |
PCM
8,16,24,32 |
2 channels CobraNet Input and Output |
2 |
2 |
CobraNet |
current |
|
ASI6012 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16,24,32 |
1 |
2 |
0 |
0 |
4/6 |
1 |
TSX time scaling |
3.14.12
and 4.04.xx starting with 4.04.04 |
|
ASI6044 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16,24,32 |
4 |
4 |
0 |
0 |
4/9 |
4 |
TSX time scaling |
3.14.12
and 4.04.xx starting with 4.04.04 |
|
ASI6114 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16, 24,32 |
1 |
4 |
1 |
4 |
4 |
1 |
TSX time scaling
AES/EBU sync in
Word clock sync in
Word clock sync out |
3.14.12
and 4.04.xx starting with 4.04.04 |
|
ASI6118 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16,24,32 |
1 |
8 |
1 |
6 |
8 |
1 |
TSX time scaling
AES/EBU sync in
Word clock sync in
Word clock sync out |
3.14.12
and 4.04.xx starting with 4.04.04 |
|
ASI6122 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16,24,32 |
2 |
2 |
2 |
2 |
4/6 |
2 |
TSX time scaling
AES/EBU sync in
Word clock sync in
Word clock sync out |
3.14.12
and 4.04.xx starting with 4.04.04 |
|
ASI6244 |
Multi (MRX)
8-50kHz |
MP3
MPEG Layer 2
PCM 8,16,24,32 |
4 |
4 |
4 |
4 |
4 |
4 |
TSX time scaling
AES/EBU sync in
Word clock sync in
Word clock sync out |
3.14.12
and 4.04.xx starting with 4.04.06 |
|
ASI8702 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher)
|
8
(tuners) |
- |
- |
- |
- |
8 |
8
AM/FM tuners
|
4.02.12 |
|
ASI8703 |
8-48kHz |
PCM 8,16,24,32 |
8
(tuners) |
- |
- |
- |
- |
8 |
8
FM/NTSC-TV tuners
|
4.02.12 |
|
ASI8705 |
8-48kHz |
PCM 8,16,24,32
|
8
(tuners) |
- |
- |
- |
- |
8 |
4 AM/FM & 4 FM/NTSC-TV tuners
|
4.02.12 |
|
ASI8712 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
4
(tuners) |
- |
- |
- |
- |
4 |
4 AM/FM tuners
|
4.02.12 |
|
ASI8713 |
8-48kHz |
PCM 8,16,24,32
|
4
(tuners) |
- |
- |
- |
- |
4 |
4 FM/NTSC-TV tuners
|
4.02.12 |
|
ASI8722 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
8
(tuners) |
- |
- |
- |
- |
8 |
6
AM/FM & 2 NTSC-TV tuners
|
4.02.12 |
|
ASI8723 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
8
(tuners) |
- |
- |
- |
- |
8 |
8 NTSC-TV tuners
|
4.02.12 |
|
ASI8724 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
4
(tuners) |
- |
- |
- |
- |
4 |
4 NTSC-TV tuners
|
4.02.12 |
|
ASI8725 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher)
|
8
(tuners) |
- |
- |
- |
- |
8 |
4
AM/FM & 4 NTSC-TV tuners
|
4.02.12 |
|
ASI8732 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
8
(tuners) |
- |
- |
- |
- |
8 |
6
AM/FM & 2 PAL-TV tuners
|
4.02.12 |
|
ASI8733 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
8
(tuners) |
- |
- |
- |
- |
8 |
8 PAL-TV tuners
|
4.02.12 |
|
ASI8734 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher) |
4
(tuners) |
- |
- |
- |
- |
4 |
4 PAL-TV tuners
|
4.02.12 |
|
ASI8735 |
8-48kHz |
PCM 8,16,24,32
MP3 (rev
H and higher)
|
8
(tuners) |
- |
- |
- |
- |
8 |
4
AM/FM & 4 PAL-TV tuners
|
4.02.12 |
* All inputs/outputs are
stereo.. |
